| 10/100 Ethernet Interfaces | 24 |
| Uplink Interfaces | 2 (SFP or 1000BASE-T) |
| Cisco IOS Software Feature Set | LAN Lite |
| Available PoE Power | 370W (24 ports up to 15.4W) |
| Flash memory | 64 MB |
| DRAM | 128 MB |
| Forwarding bandwidth | 16 Gbps |
| Maximum active VLANs | 644 |
| VLAN IDs available | 4K |
| Maximum transmission unit (MTU) – L3 packet | 9000 bytes |
| Jumbo frame – Ethernet frame | 9018 bytes |
| Forwarding Rate: 64-Byte L3 Packets, Millions of packets per second | 6.5 |
| Dimensions (H x W x D) | 1.73 x 17.70 x 13.07 in (4.4 x 45.0 x 33.2 cm) |
| Weight | 12 lb (5.4 Kg) |
| Package Weight | 20.26 lb (9.19 Kg) |
| Operating temperature up to 5000 ft (1500 m) | 23º to 113ºF (-5º to 45ºC) |
| Operating temperature up to 10,000 ft (3000 m) | 23º to 104ºF (-5º to 40ºC) |
| Short-term exception at sea level* | 23º to 131ºF (-5º to 55ºC) |
| Short-term exception up to 5000 feet (1500 m)* | 23º to 122ºF (-5º to 50ºC) |
| Short-term exception up to 10,000 feet (3000 m)* | 23º to 113ºF (-5º to 45ºC) |
| Short-term exception up to 13,000 feet (4000 m)* | 23º to 104ºF (-5º to 40ºC) |
| Storage temperature up to 15,000 feet (4573 m) | 23º to 158ºF (-25º to 70ºC) |
| Operating altitude | Up to 10,000 Feet (Up to 3,000 Meters) |
| Storage altitude | Up to 13,000 Feet (Up to 4,000 Meters) |
| Operating relative humidity | 10% to 95% noncondensing |
| Storage relative humidity | 10% to 95% noncondensing |
| Sound Pressure, dBA | Typical, LpAm: 33 Maximum, LpAD: 36 |
| Sound Power, dbA | Typical, LwA: 43 Maximum, LwAD: 46 |
| MTBF in thousands of hours | 381 |
| Ethernet Interfaces |
|
| Indicator LEDs |
|
| Console | Cisco Catalyst console cables:
|
| Power |
|
| Management |
|
| Standards |
|
| RFC compliance |
|
| Voltage (Autoranging) | 100 to 240 VAC |
| Current (Amperes) | 4.0 – 2.0 |
| Frequency | 50 to 60Hz |
| Power Rating (kVA) | 0.43 |
| DC Input Voltages (RPS Input) | 2A at 12V (7A at -52V) |
| Power Consumption | 0% traffic: 35.0 10% traffic: 34.8 100% traffic: 35.2 ATIS weighted average: 34.9 |
| Regulatory Compliance | Products should comply with CE Marking per directives 2004/108/EC and 2006/95/EC |
| Safety | UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition IEC 60950-1 Second Edition AS/NZS 60950-1 |
| EMC – Emissions | 47CFR Part 15 (CFR 47) Class A AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class A CNS13438 Class A |
| EMC – Immunity | EN55024 CISPR24 EN300386 KN24 |
| Environmental | Reduction of Hazardous Substances (RoHS) including Directive 2011/65/EU |
